VCD Series
Feedback
Description
VCD Series
| No. | ???? | ??? |
| 1 | 104-500 | VALVE |
| 2 | 109-003 | VALVE |
| 3 | CAI-302 | BAR SHEAR(R.H) 5 M/M |
| 4 | CAI-303 | BAR SHEAR(L.H) 5 M/M |
| 5 | CL-590J | COLLAR,ROCKER ARM RETAINING |
| 6 | CL-657J | COLLAR ADJUSTING |
| 7 | CL-666J | COLLAR,TAPE WHEEL DRIVE SHFT |
| 8 | CL-690J | SPACER |
| 9 | DIP-1988 | SCREW ADJUSTING |
| 10 | DIP-3010+ | RIB,FIXTURE REAR |
| 11 | DIP-3011+ | RIB |
| 12 | ED-10403 | SWITCH HEAD UP |
| 13 | ED-10403-1 | SWITCH HEAD UP BRACKET |
| 14 | ED-12301-1 | FUSE |
| 15 | ED-14834 | RELAY DC24V |
| 16 | ED-17531 | TABLE ZERO SWITCH |
| 17 | GIS-748 | O-RING |
| 18 | GR-253 | BALL STEEL(3/16) |
| 19 | GR-266 | BALL TRANSFER |
| 20 | GS-59 | LOADER SENSOR |
| 21 | GS-5N | SENSOR PHOTO |
| 22 | HPDI-601 | CAM FOLLOWER,DISC EDGE |
| 23 | HPDI-969 | VALVE FLOW CONTROL |
| 24 | NC-21U2 | NUT,LOCKING |
| 25 | NEF-47 | RING,CONVEYOR CHAIN PIN RETA |
| 26 | NL-1062K | LOCK NUT TRUNNION |
| 27 | NL-1187K | NUT |
| 28 | NL-1242K | NUT,DISPENSER INDEX DETENT |
| 29 | NL-1305K | NUT,PULLEY |
| 30 | NL-1330K | LOCK,NUT |
| 31 | NL-1374K | NUT LEVER ARM SHOULDER |
| 32 | NL-13M1 | NUT |
| 33 | NL-1441K | NUT |
| 34 | NL-16U1 | NUT |
| 35 | NL-17M1 | NUT |
| 36 | NL-17U1 | NUT,SCREW SUPPORT |
| 37 | NL-18U1 | CHECK NUT |
| 38 | NL-20U2 | NUT,PISTON ROCKING |
| 39 | NL-24U2 | LOCK NUT CLEVIS |
| 40 | NL-7M7 | NUT |
| 41 | PCI-122 | BEARING,BRACKET NEEDLE |
| 42 | PCI-1639 | CAP LINK RETAINING |
| 43 | PCI-1786A | SEAT BALL UNIT ASSY |
| 44 | PCI-180 | RAIL |
| 45 | PCI-1808 | RAIL STATIONARY |
| 46 | PCI-187 | RETAINER KNIFE |
| 47 | PCI-188 | PALTE |
| 48 | PCI-189 | SHIELD |
| 49 | PCI-192 | WIPER |
| 50 | PCI-193 | RETAINER |
| No. | ???? | ??? |
| 51 | PCI-342 | BEARING |
| 52 | PCI-363 | KNIFE FIXED |
| 53 | PCI-363A | FIXED KNIFE(C) |
| 54 | PCI-395 | SCREW DRIVER STOP |
| 55 | PCI-492 | WASHER |
| 56 | PL-1002P | PIN |
| 57 | PL-1002P-1 | PIN,CLEVIS |
| 58 | PL-1055P | PIN |
| 59 | PL-1426P | PIN |
| 60 | PL-3184P | PIN |
| 61 | PL-4196P | PIN DRIVER |
| 62 | PL-4331P | PIN |
| 63 | PL-4389P | |
| 64 | PL-5888P | PIN |
| 65 | PL-5894P | PIN |
| 66 | PL-5959P | PIN |
| 67 | PL-6218P | PIN SPRING |
| 68 | PL-634P | PIN |
| 69 | PL-6665P | PIN |
| 70 | PL-6678P | PIN FIXED KNIFE |
| 71 | PL-6684P | SHAFT,ROCKER VERTICAL |
| 72 | PL-6821P | PIN |
| 73 | SL-10N10 | SCREW |
| 74 | SL-10S4 | SCREW,BEARLNG |
| 75 | SL-11A25 | SCREW |
| 76 | SL-11H11 | SCREW |
| 77 | SL-11H13 | SCREW |
| 78 | SL-11H15 | SCREW |
| 79 | SL-11H17 | SCREW |
| 80 | SL-11H5 | SCREW |
| 81 | SL-11H7 | SCREW |
| 82 | SL-11H9 | SCREW |
| 83 | SL-11N25 | SCREW |
| 84 | SL-11S11 | SCREW,GULDE |
| 85 | SL-11S15 | SCREW |
| 86 | SL-11S5 | SCREW |
| 87 | SL-11S9 | SCREW |
| 88 | SL-12N6 | SCREW |
| 89 | SL-13A27 | SCREW |
| 90 | SL-13H17 | SCREW |
| 91 | SL-13H21 | SCREW |
| 92 | SL-13H5 | SCREW |
| 93 | SL-13H9 | SCREW |
| 94 | SL-13N31 | SCREW |
| 95 | SL-13S11 | SCREW |
| 96 | SL-13S15 | SCREW |
| 97 | SL-13S7 | SCREW |
| 98 | SL-15H9 | SCREW |
| 99 | SL-15S11 | SCREW |
| 100 | SL-17H19 | SCREW |
| 101 | SL-17N29 | SCREW |
| 102 | SL-20S36 | SCREW |
| 103 | SL-3D15 | SCREW |
| 104 | SL-3H11 | SCREW |
| 105 | SL-3H3 | SCREW |
| 106 | SL-3H5 | SCREW |
| 107 | SL-3H7 | SCREW |
| 108 | SL-3H9 | SCREW |
| 109 | SL-3N7 | SCREW |
| 110 | SL-3S3 | SET SCREW,SPRING ADJUSTING |
| 111 | SL-3S5 | SCREW |
| 112 | SL-3S7 | SCREW |
| 113 | SL-7C9 | SCREW CLAMP |
| 114 | SL-7D15 | SCREW, INTERRUPTER |
| 115 | SL-7H3 | SCREW |
| 116 | SL-7H5 | SCREW |
| 117 | SL-7H7 | SCREW |
| 118 | SL-7H9 | SCREW |
| 119 | SL-7N5 | SCREW |
| 120 | SL-7S3 | SCREW |
| 121 | SL-7S5 | SCREW |
| 122 | SL-8504V | SPRING SCREW |
| 123 | SL-8687V | SCREW |
| 124 | SL8699V | SCREW |
| 125 | SL-8784V | SCREW |
| 126 | SL-8985V | SCREW GUIDE |
| 127 | SL-8S2 | SCREW |
| 128 | SL-9008V | SCREW |
| 129 | SL-9069V | SCREW |
| 130 | SL-9074 | SCREW |
| 131 | SL-9156V | SCREW |
| 132 | SL-9191V | SCREW |
| 133 | SL9208V | SCREW |
| 134 | SL-9214V | SCREW |
| 135 | SL-9236V | SCREW |
| 136 | SL-9239V | SCREW |
| 137 | SL-9262V | SCREW RETAINER |
| 138 | SL-9D15 | SCREW |
| 139 | SL-9D29 | SCREW |
| 140 | SL-9H13 | SCREW |
| 141 | SL-9H3 | SCREW |
| 142 | SL-9H5 | SCREW |
| 143 | SL-9H9 | SCREW |
| 144 | SL-9N3 | SCREW |
| 145 | SL-9N5 | SCREW |
| 146 | SL-9N7 | SCREW |
| 147 | SL-9N9 | SCREW |
| 148 | SL-9S15 | SCREW |
| 149 | SL-9S5 | SCREW |
| 150 | SPGL-2665S | SPRING |
| 151 | SPGL-2930S | SPRING |
| 152 | SPGL-605S | SPRING |
| 153 | STA-25 | RING RETAINER |
| 154 | STA-83 | RING, RETAINER |
| 155 | TCF-496 | RING, RETAINER |
| 156 | UA-2299 | O-RING |
| 157 | UA-3004 | O-RING(7.5*3) |
| 158 | UCSM-1018 | SHAFT DRIVE GEAR |
| 159 | UCSM-1065 | PLATE CHAIN OUTSIDE |
| 160 | UCSM-1067 | O-RING |
| 161 | UCSM-1088 | PLATE CHAIN INSIDE |
| 162 | UCSM-1090 | PIN, CONVEYOR CHAIN |
| 163 | UCSM-110 | HOUSING CLUTCH |
| 164 | UCSM-110A | HOUSHING CLUCH ASSY |
| 165 | UCSM-111A | DRIVE CLUTCH |
| 166 | UCSM-1170 | STOP COMPONENT |
| 167 | UCSM-1209 | STOP COMPONENT |
| 168 | UCSM-1241 | FULCRUM DISPENSER |
| 169 | UCSM-125 | BUSHING |
| 170 | UCSM-1258 | GUIDE, TAPE REAR-DISPENSER |
| 171 | UCSM-1356 | WHEEL,TAPING |
| 172 | UCSM-1357 | SHAFT |
| 173 | UCSM-1360 | PLATE CHAIN OUTSIDE |
| 174 | UCSM-1361 | PLATE CHAIN INSIDE |
| 175 | UCSM-142 | SPRING DISPENSER |
| 176 | UCSM-1424+ | GUIDE, SIDE PLATE RADIAL-INSIDE |
| 177 | UCSM-1425+ | GUIDE, SIDE PLATE RADIAL-OUTSIDE |
| 178 | UCSM-143 | PIN, PRESSURE ROLL |
| 179 | UCSM-1505 | LINK, SLOTTED |
| 180 | UCSM-1506+ | LINK,PIN-ASSEMBLED |
| 181 | UCSM-1507 | LINK |
| 182 | UCSM-1508+ | LINK PIN |
| 183 | UCSM-1509 | LINK |
| 184 | UCSM-1510+ | LINK, PIN-ASSEMBLED |
| 185 | UCSM-152+ | ARM |
| 186 | UCSM-153+ | ARM |
| 187 | UCSM-1566 | STOP COMPONENT |
| 188 | UCSM-159A | GEAR, DRIVEN |
| 189 | UCSM-160 | KEY DRIVER GEAR |
| 190 | UCSM-161 | ROD PRESSURE ROLL FULCRUM |
| 191 | UCSM-168 | WHEEL TAPING |
| 192 | UCSM-1732 | GUIDE COMPONENT |
| 193 | UCSM-1747 | BLOCK CONTACT RAMP |
| 194 | UCSM-1804 | STRIPPER COMPONENT-R.H |
| 195 | UCSM-1805 | STRIPPER COMPONENT-L.H |
| 196 | UCSM-1813 | TRACK CARRIER-FRONT |
| 197 | UCSM-1814 | TRACK CARRIER-REAR |
| 198 | UCSM-1816 | SUPPORT UPPER COMPONENT |
| 199 | UCSM-182 | SHAFT CUTTER KNIFE |
| 200 | UCSM-184 | SHAFT DISPENSER |
| 201 | UCSM-1857 | CONTACY LOWER UNIT |
| 202 | UCSM-1869 | STOP COMPONENT |
| 203 | UCSM-1926 | STOP COMPONENT-ASSEMBLY |
| 204 | UCSM-1927+ | BRACKET PRESSURE ROLL |
| 205 | UCSM-1972 | OUTSIDE FINGER |
| 206 | UCSM-1973 | INSIDE FINGER |
| 207 | UCSM-1999 | BLOCK |
| 208 | UCSM-2 | PLATE CONVEYOR CHAIN SIDE |
| 209 | UCSM-2001 | PIVOT SOLENOID MOUNTING |
| 210 | UCSM-2002 | BASE SOLENOID MOUNTING |
| 211 | UCSM-202A | PIN SOLENOID PIVOT |
| 212 | UCSM-2080 | STRIP CONVEYOR GUIDE-UPPER |
| 213 | UCSM-2081 | BLOCK CHAIN SIDE PLATE SET-UP |
| 214 | UCSM-2082 | SPRING COMPONENT LIET |
| 215 | UCSM-209 | PLATE |
| 216 | UCSM-210 | SHAFT REDUCER DRIVE |
| 217 | UCSM-211 | PLATE ADJUSTABLE DRINVE |
| 218 | UCSM-2112 | SCREW THUMB COMPONENT GUIDE |
| 219 | UCSM-212 | SHAFT CONVEYOR CHAIN DRIVE |
| 220 | UCSM-2128 | GUIDE COMPONENT POSITIONING |
| 221 | UCSM-2129 | GUIDE COMPONENT POSITIONING |
| 222 | UCSM-213 | SHAFT |
| 223 | UCSM-2149 | WHEEL CUTTING OUTSIDE |
| 224 | UCSM-2150 | WHEEL CUTTING INSIDE |
| 225 | UCSM-2151 | KNIFE CUTTER |
| 226 | UCSM-2165 | WHEEL |
| 227 | UCSM-2166 | WHEEL |
| 228 | UCSM-2231 | BAND BRAKE |
| 229 | UCSM-2232 | ANCHOR |
| 230 | UCSM-2242 | STRIP CONVEYOR GUIDE-UPPER |
| 231 | UCSM-2246 | BLOCK CHAIN SIDE PLATE SET-UP |
| 232 | UCSM-2255 | STOP COMPONENT-ASSEMBLY |
| 233 | UCSM-2308 | BLOCK UPPER CONTACT |
| 234 | UCSM-2309 | BLOCK UPPER CONTACT |
| 235 | UCSM-2325 | CONTACT UPPER UNIT |
| 236 | UCSM-2356 | GUIDE TAPE-OUTSIDE |
| 237 | UCSM-2357 | GUIDE TAPE INSIDE |
| 238 | UCSM-2392 | ROLL PRESSURE ASSEMBLY |
| 239 | UCSM-2409 | STRIP CONVEYOR GUIDE-UPPER |
| 240 | UCSM-2502 | WHEEL TAPING |
| 241 | UCSM-2527 | ARM SHAFT OPERATING LEVER ASSY |
| 242 | UCSM-2531 | SPROCKET CONVEYOR CHAIN DRIVE |
| 243 | UCSM-2606 | SUPPORT BODY CENTERING PIVOT |
| 244 | UCSM-2607 | BASE |
| 245 | UCSM-2608 | PAN SPRING |
| 246 | UCSM-2750 | SOLENOID FRONT |
| 247 | UCSM-2769 | LEVER |
| 248 | UCSM-2784 | CLUTCH SHAFT |
| 249 | UCSM-2804 | FULCRUM |
| 250 | UCSM-2811 | SCREW |
| 251 | UCSM-2814 | GEAR |
| 252 | UCSM-2835 | SHAFT |
| 253 | UCSM-2847 | SPRING |
| 254 | UCSM-2857 | KEY DISPNDING WHEEL |
| 255 | UCSM-294A | COLLAR CLUTCH STOP |
| 256 | UCSM-2972 | WHEEL CUTTING-INSIDE |
| 257 | UCSM-2973 | WHEEL CUTTING-OUTSIDE |
| 258 | UCSM-3 | PLATE |
| 259 | UCSM-3047 | KEY |
| 260 | UCSM-3110 | BASE |
| 261 | UCSM-3111+ | HOUSING |
| 262 | UCSM-3112+ | HOUSING |
| 263 | UCSM-3113+ | HOUSING |
| 264 | UCSM-3115 | PIN CONVEYOR CHAIN |
| 265 | UCSM-3116 | PLATE CONVEYOR CHAIN |
| 266 | UCSM-3117 | PLATE CONVEYOR CHAIN |
| 267 | UCSM-3118 | PLATE CONVEYOR CHAIN SIDE |
| 268 | UCSM-3119 | PLATE CONVEYOR CHAIN SIDE |
| 269 | UCSM-3123 | TRACK CARRIER |
| 270 | UCSM-3124 | TRACK CARRIER |
| 271 | UCSM-3125 | STRIP |
| 272 | UCSM-3164 | LEAD-IN CENTERING BODY-C |
| 273 | UCSM-3165 | LEAD-IN CENTERING BODY-B |
| 274 | UCSM-3168 | SUPPORT CHAUN |
| 275 | UCSM-3169 | SHAFT CONVEYOR CHAIN DRIVE |
| 276 | UCSM-3170 | SHAFT TAPE WHEEL DRIVE |
| 277 | UCSM-3183 | DISC INTERRUPTER TIMING |
| 278 | UCSM-3185 | DRIVER CLUTCH |
| 279 | UCSM-3185A | DRIVER CLUTCH ASSY(개조) |
| 280 | UCSM-3186+ | BLOCK SHAFT BEARING |
| 281 | UCSM-3190 | BASE SOLENOID MOUNTING |
| 282 | UCSM-3203 | SHAFT TOP SUPPORT |
| 283 | UCSM-3206 | SHAFT DRIVING |
| 284 | UCSM-3210 | WASHER |
| 285 | UCSM-3215 | STOP COMPONENT |
| 286 | UCSM-3217 | SHAFT AUXILIARY |
| 287 | UCSM-3220 | WHEEL COMPONENT GUIDE |
| 288 | UCSM-3221 | GEAR DRIVER |
| 289 | UCSM-3257 | KEY INDEX WHEEL |
| 290 | UCSM-3258 | SHOULDER SCREW |
| 291 | UCSM-3260 | LEVER PRESSURE ROLL |
| 292 | UCSM-3278 | WASHER CUTTER |
| 293 | UCSM-3300 | INDEX WHEEL |
| 294 | UCSM-3316 | SUPPORT |
| 295 | UCSM-3318 | SUPPORT |
| 296 | UCSM-3319 | SUPPORT COMPONENT LOWER |
| 297 | UCSM-3357 | BEARING FLANGED SLEEVE |
| 298 | UCSM-3362 | KNOB TOP |
| 299 | UCSM-3365 | SOLENOID REAR |
| 300 | UCSM-3367 | SOLENOID FRONT |
| 301 | UCSM-3368 | SOLENOID DISPNSER FRONT |
| 302 | UCSM-3387 | SHAFT DRIVER |
| 303 | UCSM-3439 | INTERRUPTER SENSOR |
| 304 | UCSM-3455 | ROLLER |
| 305 | UCSM-3462 | BODY CENTERING GUIDE |
| 306 | UCSM-3469 | LEVER INDEX |
| 307 | UCSM-3484 | NUT |
| 308 | UCSM-3500 | WHEEL INSIDE |
| 309 | UCSM-3509 | CUTTER OUTSIDE |
| 310 | UCSM-3510 | CUTTER INSIDE |
| 311 | UCSM-3511 | WHEEL OUTSIDE |
| 312 | UCSM-3516 | STOP COMPONENT |
| 313 | UCSM-3530 | CARRIER |
| 314 | UCSM-3531 | CARRIER |
| 315 | UCSM-3620 | KNOB BOTTOM |
| 316 | UCSM-3636 | COUPLE PRESSURE ROLL-L |
| 317 | UCSM-3637 | COUPLE PRESSURE ROLL-R |
| 318 | UCSM-3655 | SPACER,BOTTOM KNOB |
| 319 | UCSM-3656 | CHUTE GUIDE FRONT INSIDE |
| 320 | UCSM-3657 | CHUTE GUIDE FRONT OUTSIDE |
| 321 | UCSM-3667 | GUIDE COMPONENT-INSIDE |
| 322 | UCSM-3668 | GUIDE COMPONENT-OUTSIDE |
| 323 | UCSM-367 | BASE |
| 324 | UCSM-3676 | STOP COMPONENT |
| 325 | UCSM-3677 | ROLLER |
| 326 | UCSM-3695 | COLLAR SHAFT |
| 327 | UCSM-370 | STOP COMPONENT |
| 328 | UCSM-3756 | STOP COMPONENT |
| 329 | UCSM-3757 | WHEEL GUIDE OUTSIDE |
| 330 | UCSM-3758 | WHEEL GUIDE INSIDE |
| 331 | UCSM-3761 | SPRING GUIDE WHEEL |
| 332 | UCSM-3763 | CHUTE OUTSIDE |
| 333 | UCSM-3764 | CHUTE INSIDE |
| 334 | UCSM-3768 | WHEEL TAPE GUIDE |
| 335 | UCSM-3769 | WHEEL TAPE GUIDE |
| 336 | UCSM-3782 | SPRING CLIP |
| 337 | UCSM-3798 | HOUSING BODY |
| 338 | UCSM-3798-1 | HOUSING BODY SHAFT |
| 339 | UCSM-3805 | CENTERING FINGER |
| 340 | UCSM-3805A | CENTERING UNIT ASSY(G-TYPE) |
| 341 | UCSM-3808 | PLATE |
| 342 | UCSM-3811 | BRACKET |
| 343 | UCSM-3818 | SPINDEL |
| 344 | UCSM-3832 | SHAFT |
| 345 | UCSM-3858 | GEAR |
| 346 | UCSM-3865 | CABLE,MICROSWITCH TAPE BREAK |
| 347 | UCSM-394 | STUD PRESSURE ROLL |
| 348 | UCSM-4028 | PLATE CONVEYOR |
| 349 | UCSM-4029 | PLATE CONVEYOR |
| 350 | UCSM-4031 | PLATE CONVEYOR |
| 351 | UCSM-4032 | PLATE CONVEYOR |
| 352 | UCSM-4053 | STANDOFF |
| 353 | UCSM-4069 | BRACKET |
| 354 | UCSM-4113 | SUPPORT COMPONENT LOWER |
| 355 | UCSM-4118 | SPRING,BODY SUPPORT |
| 356 | UCSM-4139 | PIN |
| 357 | UCSM-4178 | BUSHING |
| 358 | UCSM-4355 | ROLLER INDEXING |
| 359 | UCSM-507 | BLOCK |
| 360 | UCSM-530 | SCREW |
| 361 | UCSM-588 | SHOULDER SCREW |
| 362 | UCSM-589 | LINK ARM OPERATING |
| 363 | UCSM-643 | DISC BRAKE BAND |
| 364 | UCSM-645 | WHEEL TAPING |
| 365 | UCSM-669 | ROLL DISPENSER |
| 366 | UCSM-689 | STOP COMPONENT ASS'Y |
| 367 | UCSM-767 | SUPPORT COMPONENT LOWER |
| 368 | UCSM-768 | SUPPORT COMPONENT LOWER |
| 369 | UCSM-77A | WHEEL DISPENSER INDEX |
| 370 | UCSM-79A | GUIDE CHUTE REAR-LH |
| 371 | UCSM-80A | GUIDE CHUTE REAR-RH |
| 372 | UCSM-808 | SPRING FINGER RETURN |
| 373 | UCSM-862 | SPRING COMPONENT LIFT |
| 374 | UCSM-876+ | BASE COMPONENT SUPPORT |
| 375 | UCSM-878A | GUIDE CHUTE FRONT-RH |
| 376 | UCSM-879A | GUIDE CHUTE FRONT-LH |
| 377 | UCSM-881+ | HOUSING |
| 378 | UCSM-882 | SCREW SUPPORT ADJUSTING |
| 379 | UCSM-885+ | HOUSING BODY CENTERING PIVOT |
| 380 | UCSM-886 | PIN,HOUSING FULCRUM |
| 381 | UCSM-894 | SPRING FINGER RETURN |
| 382 | UCSM-950 | WHEEL TAPING |
| 383 | UCSM-9501 | DRIVER CLUTCH ASSY(개조) |
| 384 | UCSM-951 | SUPPORT COMPONENT LOWER |
| 385 | UCSM-955+ | HOUSING BODY CENTERING PIVOT |
| 386 | UCSM-969 | SPRING FINGER RETURN |
| 387 | UCSM-979+ | LEVER DISPENSER |
| 388 | UCSM-980 | PIN CONVEYOR CHAIN |
| 389 | UCSM-981 | PIN CONVEYOR CHAIN |
| 390 | UEF-504 | O-RINR |
| 391 | UFFM-78 | BUSHING |
| 392 | UGHS-42 | BELT |
| 393 | USCM-1971 | RETAINER COMPONENT WIRE |
| 394 | VCD-10 | GUIDE |
| 395 | VCD-107A | SHEAR BLOCK |
| 396 | VCD-108A | SHEAR BLOCK |
| 397 | VCD-109 | WHEEL INDEXING |
| 398 | VCD-11 | HOUSING BEARING |
| 399 | VCD-1123 | BRACKET |
| 400 | VCD-1124 | UPPER IDLER PULLEY SHAFT |
